Fiber laser cutting machine outputs a high-energy-density laser beam through the fiber laser and focuses it on the surface of the workpiece, causing the area on the workpiece illuminated by the ultra-fine focus spot to instantly melt and vaporize. The CNC mechanical system moves the spot irradiation position to achieve automatic cutting. It can be used for both plane cutting and bevel cutting, and its edges are neat and smooth. It is suitable for high-precision cutting such as metal plates. At the same time, it can be used for three-dimensional cutting with the addition of a robotic arm.

Details of RB1530 CNC PLAMSA CUTTING  MACHINE FOR PLATE AND  ROUND/SQUARED TUBE:

1.High strength machine bed is more stable and durable. After 600℃ stress relief annealing treatment, the machine bed has strong structural rigidity. The overall mechanical structure of the machine has small deformation, low vibration, ensure cutting accuracy.

2.Professional industrial aluminum material.Good steel property, light weight, and small inertia. Improve cutting speed and life.

3.The laser cutting machine remote control is a device used to control the laser cutting machine, which has multiple functions, including on/off, mode switching, parameter setting, controlling XY translation and Z-axis lifting, etc.

4.The BM110 series is an autofocus laser cutting head. This product is equipped with a built-in motor drive unit, which drives the focusing mirror to automatically change position within a range of 24mm through a linear mechanism. Users can set continuous focusing through a program to complete rapid perforation of thick plates and automatic cutting of plates of different thicknesses and materials.

5.This laser generator has higher photoelectric conversion efficiency, better and more stable beam quality, stronger anti high reflection ability, and introduces an optimized second-generation fiber optic transmission system to ensure a more stable and precise cutting effect in thick plate cutting.

6.Equipped with servo motor, high precision realizes closed-loop control of position, speed and torque, with good high-speed performance.

TECHNICAL PARAMETERS:

Model	RB1530
Working Voltage	220V±15%, 50/60Hz, 1PH, CNC machine. 220/380V±15%, 50/60Hz, 1/3 PH, Laser generator
Maximum cutting size	1500*3000mm
Maximum Speed	100m/min
Cutting Thickness	0-100mm (Depends on different laser generator)
Plasma Power	1500W/2000W/3000W/6000W/12000W/20000W

Main Specification：

Control System	CYPCUT
Laser generator	RAYCUS
Laser head	RAYTOOLS
Driving System	INOVANCE Servo driving system
Water cooler	S&A
Guide Rail	HIWIN square orbit,
Transmission Method	Gear transmission
Reducer	SHIMPO
Software	Cypnest
Transmission system	Gantry double-drive structure
Lubrication system	Full-automatic
Packing Type	Standard plywood case
Table	Saw tooth table
Smoke Removal Method	Fan
Graphic format supported	CAD. DXF (etc)
Working environment	Temp:0-40℃, humidity≤80%
